Load Caffe framework models

Table of Contents

Next Tutorial: How to enable Halide backend for improve efficiency

Original author Vitaliy Lyudvichenko
Compatibility OpenCV >= 3.3

Introduction

In this tutorial you will learn how to use opencv_dnn module for image classification by using GoogLeNet trained network from Caffe model zoo.

We will demonstrate results of this example on the following picture.

Source Code

We will be using snippets from the example application, that can be downloaded here.

#include <fstream>
#include <sstream>
#include <iostream>
#include <opencv2/dnn.hpp>
#include <opencv2/imgproc.hpp>
#include <opencv2/highgui.hpp>
#include "common.hpp"
std::string keys =
"{ help h | | Print help message. }"
"{ @alias | | An alias name of model to extract preprocessing parameters from models.yml file. }"
"{ zoo | models.yml | An optional path to file with preprocessing parameters }"
"{ input i | | Path to input image or video file. Skip this argument to capture frames from a camera.}"
"{ initial_width | 0 | Preprocess input image by initial resizing to a specific width.}"
"{ initial_height | 0 | Preprocess input image by initial resizing to a specific height.}"
"{ std | 0.0 0.0 0.0 | Preprocess input image by dividing on a standard deviation.}"
"{ crop | false | Preprocess input image by center cropping.}"
"{ framework f | | Optional name of an origin framework of the model. Detect it automatically if it does not set. }"
"{ needSoftmax | false | Use Softmax to post-process the output of the net.}"
"{ classes | | Optional path to a text file with names of classes. }"
"{ backend | 0 | Choose one of computation backends: "
"0: automatically (by default), "
"1: Halide language (http://halide-lang.org/), "
"2: Intel's Deep Learning Inference Engine (https://software.intel.com/openvino-toolkit), "
"3: OpenCV implementation, "
"4: VKCOM, "
"5: CUDA, "
"6: WebNN }"
"{ target | 0 | Choose one of target computation devices: "
"0: CPU target (by default), "
"1: OpenCL, "
"2: OpenCL fp16 (half-float precision), "
"3: VPU, "
"4: Vulkan, "
"6: CUDA, "
"7: CUDA fp16 (half-float preprocess) }";
using namespace cv;
using namespace dnn;
std::vector<std::string> classes;
int main(int argc, char** argv)
{
CommandLineParser parser(argc, argv, keys);
const std::string modelName = parser.get<String>("@alias");
const std::string zooFile = parser.get<String>("zoo");
keys += genPreprocArguments(modelName, zooFile);
parser = CommandLineParser(argc, argv, keys);
parser.about("Use this script to run classification deep learning networks using OpenCV.");
if (argc == 1 || parser.has("help"))
{
parser.printMessage();
return 0;
}
int rszWidth = parser.get<int>("initial_width");
int rszHeight = parser.get<int>("initial_height");
float scale = parser.get<float>("scale");
Scalar mean = parser.get<Scalar>("mean");
Scalar std = parser.get<Scalar>("std");
bool swapRB = parser.get<bool>("rgb");
bool crop = parser.get<bool>("crop");
int inpWidth = parser.get<int>("width");
int inpHeight = parser.get<int>("height");
String model = findFile(parser.get<String>("model"));
String config = findFile(parser.get<String>("config"));
String framework = parser.get<String>("framework");
int backendId = parser.get<int>("backend");
int targetId = parser.get<int>("target");
bool needSoftmax = parser.get<bool>("needSoftmax");
std::cout<<"mean: "<<mean<<std::endl;
std::cout<<"std: "<<std<<std::endl;
// Open file with classes names.
if (parser.has("classes"))
{
std::string file = parser.get<String>("classes");
std::ifstream ifs(file.c_str());
if (!ifs.is_open())
CV_Error(Error::StsError, "File " + file + " not found");
std::string line;
while (std::getline(ifs, line))
{
classes.push_back(line);
}
}
if (!parser.check())
{
parser.printErrors();
return 1;
}
CV_Assert(!model.empty());
Net net = readNet(model, config, framework);
net.setPreferableBackend(backendId);
net.setPreferableTarget(targetId);
// Create a window
static const std::string kWinName = "Deep learning image classification in OpenCV";
namedWindow(kWinName, WINDOW_NORMAL);
VideoCapture cap;
if (parser.has("input"))
cap.open(parser.get<String>("input"));
else
cap.open(0);
// Process frames.
Mat frame, blob;
while (waitKey(1) < 0)
{
cap >> frame;
if (frame.empty())
{
waitKey();
break;
}
if (rszWidth != 0 && rszHeight != 0)
{
resize(frame, frame, Size(rszWidth, rszHeight));
}
blobFromImage(frame, blob, scale, Size(inpWidth, inpHeight), mean, swapRB, crop);
// Check std values.
if (std.val[0] != 0.0 && std.val[1] != 0.0 && std.val[2] != 0.0)
{
// Divide blob by std.
divide(blob, std, blob);
}
net.setInput(blob);
// double t_sum = 0.0;
// double t;
int classId;
double confidence;
cv::TickMeter timeRecorder;
timeRecorder.reset();
Mat prob = net.forward();
double t1;
timeRecorder.start();
prob = net.forward();
timeRecorder.stop();
t1 = timeRecorder.getTimeMilli();
timeRecorder.reset();
for(int i = 0; i < 200; i++) {
timeRecorder.start();
prob = net.forward();
timeRecorder.stop();
Point classIdPoint;
minMaxLoc(prob.reshape(1, 1), 0, &confidence, 0, &classIdPoint);
classId = classIdPoint.x;
// Put efficiency information.
// std::vector<double> layersTimes;
// double freq = getTickFrequency() / 1000;
// t = net.getPerfProfile(layersTimes) / freq;
// t_sum += t;
}
if (needSoftmax == true)
{
float maxProb = 0.0;
float sum = 0.0;
Mat softmaxProb;
maxProb = *std::max_element(prob.begin<float>(), prob.end<float>());
cv::exp(prob-maxProb, softmaxProb);
sum = (float)cv::sum(softmaxProb)[0];
softmaxProb /= sum;
Point classIdPoint;
minMaxLoc(softmaxProb.reshape(1, 1), 0, &confidence, 0, &classIdPoint);
classId = classIdPoint.x;
}
std::string label = format("Inference time of 1 round: %.2f ms", t1);
std::string label2 = format("Average time of 200 rounds: %.2f ms", timeRecorder.getTimeMilli()/200);
putText(frame, label, Point(0, 15), FONT_HERSHEY_SIMPLEX, 0.5, Scalar(0, 255, 0));
putText(frame, label2, Point(0, 35), FONT_HERSHEY_SIMPLEX, 0.5, Scalar(0, 255, 0));
// Print predicted class.
label = format("%s: %.4f", (classes.empty() ? format("Class #%d", classId).c_str() :
classes[classId].c_str()),
confidence);
putText(frame, label, Point(0, 55), FONT_HERSHEY_SIMPLEX, 0.5, Scalar(0, 255, 0));
imshow(kWinName, frame);
}
return 0;
}
cv::CommandLineParser
Designed for command line parsing.
Definition: utility.hpp:818
cv::Mat
n-dimensional dense array class
Definition: mat.hpp:811
cv::Mat::reshape
Mat reshape(int cn, int rows=0) const
Changes the shape and/or the number of channels of a 2D matrix without copying the data.
cv::Mat::end
MatIterator_< _Tp > end()
Returns the matrix iterator and sets it to the after-last matrix element.
cv::Mat::begin
MatIterator_< _Tp > begin()
Returns the matrix iterator and sets it to the first matrix element.
cv::Point_< int >
cv::Point_::x
_Tp x
x coordinate of the point
Definition: types.hpp:201
cv::Scalar_< double >
cv::Size_
Template class for specifying the size of an image or rectangle.
Definition: types.hpp:335
cv::TickMeter
a Class to measure passing time.
Definition: utility.hpp:295
cv::TickMeter::start
void start()
starts counting ticks.
Definition: utility.hpp:304
cv::TickMeter::stop
void stop()
stops counting ticks.
Definition: utility.hpp:310
cv::TickMeter::reset
void reset()
resets internal values.
Definition: utility.hpp:374
cv::TickMeter::getTimeMilli
double getTimeMilli() const
returns passed time in milliseconds.
Definition: utility.hpp:333
cv::VideoCapture
Class for video capturing from video files, image sequences or cameras.
Definition: videoio.hpp:728
cv::VideoCapture::open
virtual bool open(const String &filename, int apiPreference=CAP_ANY)
Opens a video file or a capturing device or an IP video stream for video capturing.
cv::exp
void exp(InputArray src, OutputArray dst)
Calculates the exponent of every array element.
cv::divide
void divide(InputArray src1, InputArray src2, OutputArray dst, double scale=1, int dtype=-1)
Performs per-element division of two arrays or a scalar by an array.
cv::sum
Scalar sum(InputArray src)
Calculates the sum of array elements.
cv::minMaxLoc
void minMaxLoc(InputArray src, double *minVal, double *maxVal=0, Point *minLoc=0, Point *maxLoc=0, InputArray mask=noArray())
Finds the global minimum and maximum in an array.
cv::String
std::string String
Definition: cvstd.hpp:152
cv::format
String format(const char *fmt,...)
Returns a text string formatted using the printf-like expression.
CV_Error
#define CV_Error(code, msg)
Call the error handler.
Definition: base.hpp:320
CV_Assert
#define CV_Assert(expr)
Checks a condition at runtime and throws exception if it fails.
Definition: base.hpp:342
cv::dnn::blobFromImage
Mat blobFromImage(InputArray image, double scalefactor=1.0, const Size &size=Size(), const Scalar &mean=Scalar(), bool swapRB=false, bool crop=false, int ddepth=CV_32F)
Creates 4-dimensional blob from image. Optionally resizes and crops image from center,...
cv::dnn::readNet
Net readNet(const String &model, const String &config="", const String &framework="")
Read deep learning network represented in one of the supported formats.
cv::imshow
void imshow(const String &winname, InputArray mat)
Displays an image in the specified window.
cv::waitKey
int waitKey(int delay=0)
Waits for a pressed key.
cv::namedWindow
void namedWindow(const String &winname, int flags=WINDOW_AUTOSIZE)
Creates a window.
cv::putText
void putText(InputOutputArray img, const String &text, Point org, int fontFace, double fontScale, Scalar color, int thickness=1, int lineType=LINE_8, bool bottomLeftOrigin=false)
Draws a text string.
cv::resize
void resize(InputArray src, OutputArray dst, Size dsize, double fx=0, double fy=0, int interpolation=INTER_LINEAR)
Resizes an image.
cv
"black box" representation of the file storage associated with a file on disk.
Definition: core.hpp:106
std
STL namespace.

Explanation

  1. Firstly, download GoogLeNet model files: bvlc_googlenet.prototxt and bvlc_googlenet.caffemodel

    Also you need file with names of ILSVRC2012 classes: classification_classes_ILSVRC2012.txt.

    Put these files into working dir of this program example.

  2. Read and initialize network using path to .prototxt and .caffemodel files

    Net net = readNet(model, config, framework);
    net.setPreferableBackend(backendId);
    net.setPreferableTarget(targetId);

    You can skip an argument framework if one of the files model or config has an extension .caffemodel or .prototxt. This way function cv::dnn::readNet can automatically detects a model's format.

  3. Read input image and convert to the blob, acceptable by GoogleNet

    VideoCapture cap;
    if (parser.has("input"))
    cap.open(parser.get<String>("input"));
    else
    cap.open(0);

    cv::VideoCapture can load both images and videos.

    blobFromImage(frame, blob, scale, Size(inpWidth, inpHeight), mean, swapRB, crop);
    // Check std values.
    if (std.val[0] != 0.0 && std.val[1] != 0.0 && std.val[2] != 0.0)
    {
    // Divide blob by std.
    divide(blob, std, blob);
    }

    We convert the image to a 4-dimensional blob (so-called batch) with 1x3x224x224 shape after applying necessary pre-processing like resizing and mean subtraction (-104, -117, -123) for each blue, green and red channels correspondingly using cv::dnn::blobFromImage function.

  4. Pass the blob to the network
    net.setInput(blob);
  5. Make forward pass
    // double t_sum = 0.0;
    // double t;
    int classId;
    double confidence;
    cv::TickMeter timeRecorder;
    timeRecorder.reset();
    Mat prob = net.forward();
    double t1;
    timeRecorder.start();
    prob = net.forward();
    timeRecorder.stop();
    t1 = timeRecorder.getTimeMilli();
    timeRecorder.reset();
    for(int i = 0; i < 200; i++) {
    During the forward pass output of each network layer is computed, but in this example we need output from the last layer only.
  6. Determine the best class
    Point classIdPoint;
    minMaxLoc(prob.reshape(1, 1), 0, &confidence, 0, &classIdPoint);
    classId = classIdPoint.x;
    We put the output of network, which contain probabilities for each of 1000 ILSVRC2012 image classes, to the prob blob. And find the index of element with maximal value in this one. This index corresponds to the class of the image.
  7. Run an example from command line
    ./example_dnn_classification --model=bvlc_googlenet.caffemodel --config=bvlc_googlenet.prototxt --width=224 --height=224 --classes=classification_classes_ILSVRC2012.txt --input=space_shuttle.jpg --mean="104 117 123"
    For our image we get prediction of class space shuttle with more than 99% sureness.
